Kyocera FS-1060DN User Manual

2M2/2M3
2-3-5
Connector Pin Signal I/O Voltage Description
YC2 1 +24V3 O 24V DC 24 V DC power to DUSOL
Connected
to duplex
solenoid
(25/26 ppm
model)
2 DUSOLDRN O DC0V/24V DUSOL: On/Off
YC3 1 +24V3 O 24V DC 24 V DC power to PFSOL
Connected
to paper
feed sole-
noid
2 FFEDSOLDRN O DC0V/24V PFSOL: On/Off
YC4 1 OUTA O 0/24 V DC (pulse) MM control signal
Connected
to main
motor
2 OUTB O 0/24 V DC (pulse) MM control signal
YC5 1 +24V3 O 24V DC 24 V DC power to FM
Connected
to fan motor
2 FANDRN O DC0V/24V FM: On/Off
YC6 1 +24V3 O 24V DC 24 V DC power to TS
Connected
to toner
sensor
2 TONER SENSOR I DC0V/24V TS: On/Off
3 GND - - Ground
YC7 1 3.3V3 O 3.3 V DC 3.3 V DC power to CPWB
Connected
to container
PWB
2 SECCLK O 0/3.3 V DC (pulse) Clock signal
3 SECDATA I 0/3.3 V DC Data signal
4 GND - - Ground
YC8 1 3.3V3 O 3.3 V DCREG 3.3 V DC power to RS
Connected
to registra-
tion sensor
2 GND - - Ground
3 REGIST I 0/3.3 V DC RS: On/Off
YC9 1 3.3V3 O 3.3 V DC 3.3 V DC power to TH
Connected
to outer
tempera-
ture sensor
2 THERM I Analog Outer thermistor signal

Kyocera FS-1060DN Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1800 x 600 DPI
Time to first page (black, normal)	7.5 s
Print speed (black, normal quality, A4/US Letter)	26 ppm
Printing colors	Black
Maximum duty cycle	15000 pages per month
Number of print cartridges	1
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols (IPv4)	TCP/IP
Processor model	ARM926EJ
Maximum internal memory	- MB
Sound pressure level (printing)	50 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Total number of input trays	2
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Labels, Plain paper, Pre-Printed, Recycled paper
Paper tray media weight	60 - 220 g/m²
ISO A-series sizes (A0...A9)	A4, A5
Maximum ISO A-series paper size	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage	220 V
AC input frequency	50 Hz
Power consumption (printing)	134 W
Product color	Black, White
Networking features	Fast Ethernet
Networking standards	IEEE 802.3, IEEE 802.3u
Compatible operating systems	Windows Vista 32/64 bit\\r Windows XP 32/64 bit\\r Windows 7 32/64 bit\\r Windows Server 2003\\r Windows Server 2008 32/64 bit\\r Mac OS X

Weight and Dimensions

Dimensions (WxDxH)	358 x 276 x 241 mm
