2M2/2M3
2-3-7
Connector Pin Signal I/O Voltage Description
YC101 1 LIVE I 120 V AC
220-240 V AC
AC power input
Connected to
AC inlet
2 NEUTRAL I 120 V AC
220-240 V AC
AC power input
YC102 1 HEATER_COM O 120 V AC
220-240 V AC
AC power output
Connected to
Fuser heater
lamp
2 NC - - Not used
3 HEATER_LIVE O 120 V AC
220-240 V AC
AC power output
YC103 1 +24V2 O 24V DC 24 V DC power to MPWB
Connected to
main PWB
2 +24V2 O 24V DC 24 V DC power to MPWB
3 PSSLEEPN I 0/3.3 V DC Sleep mode signal
4 ZCROSS O 0/3.3 V DC (pulse) Zero-cross signal
5 RELAY I 0/3.3 V DC Relay signal
6 HEATREM I 0/3.3 V DC FH: On/Off
7 PUSHSW O 0/3.3 V DC PSW: On/Off
8 +24V1 O 24V DC 24 V DC power to MPWB
9 GND - - Ground
10 GND - - Ground

Kyocera FS-1060DN Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1800 x 600 DPI
Time to first page (black, normal)	7.5 s
Print speed (black, normal quality, A4/US Letter)	26 ppm
Printing colors	Black
Maximum duty cycle	15000 pages per month
Number of print cartridges	1
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols (IPv4)	TCP/IP
Processor model	ARM926EJ
Maximum internal memory	- MB
Sound pressure level (printing)	50 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Total number of input trays	2
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Labels, Plain paper, Pre-Printed, Recycled paper
Paper tray media weight	60 - 220 g/m²
ISO A-series sizes (A0...A9)	A4, A5
Maximum ISO A-series paper size	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage	220 V
AC input frequency	50 Hz
Power consumption (printing)	134 W
Product color	Black, White
Networking features	Fast Ethernet
Networking standards	IEEE 802.3, IEEE 802.3u
Compatible operating systems	Windows Vista 32/64 bit\\r Windows XP 32/64 bit\\r Windows 7 32/64 bit\\r Windows Server 2003\\r Windows Server 2008 32/64 bit\\r Mac OS X

Weight and Dimensions

Dimensions (WxDxH)	358 x 276 x 241 mm
