Kyocera FS-1060DN User Manual

2M2/2M3
1-1-2
*:The Manual Feed tray is only provided on the 25/26 ppm model.
NOTE: These specifications are subject to change without notice.
Output tray
capacity
Standard
paper
150 sheets (80 g/m
2
)
Special
paper
-
1 sheets
Continuous copying 1 to 999 sheets
Photoconductor OPC drum (drum diameter 24 mm)
Image write system Semiconductor laser (1 beam)
Charging system Charger roller
Developing system
Mono component dry developing method
Toner replenishing: Automatic from the toner container
Transfer system Transfer roller
Separation system Small diameter separation, discharger brush
Cleaning system Counter blade
Charge erasing system Exposure by eraser lamp (LED)
Fusing system
Heat roller system
Abnormally high temperature protection devices: thermostat
CPU ARM926EJ 390MHz
memory 32 MB (Maxmum 32 MB)
Interface
USB Interface connector: 1 (USB Hi-
Speed)
USB Interface connector: 1 (USB Hi-
Speed)
Network interface: 1 (10 BASE-T/
100 BASE-TX)
Resolution 600 × 600 dpi
Page Description Language KPSL
Operating
environment
Temperature 10 to 32.5 °C/50 to 90.5 °F
Humidity 15 to 80% RH
Altitude
3,500 m/11,482.8 ft or less
High altitude mode is available for regular operation at less than 1500m or
1500 – 3500m.
Brightness 1,500 lux or less
Dimensions
(W × D × H)
machine
only
358 × 262 × 241 mm
14 1/8 × 10 5/16 × 9 1/2”
358 × 276 × 241 mm
14 1/8 × 10 7/8 × 9 1/2”
Space required (W × D)
358 × 645 mm
(using paper feed tray)
14 1/8 × 13/16”
358 × 630 mm)
(using paper feed tray)
14 1/8 × 3/8”
Weight 6.3 kg/13.86 lb
6.7 kg/14.74 lb
Power source
120 V Specification Model:120 V (60 Hz, 5.4 A)
230 V Specification Model: 220 to 240 V (50 Hz/60 Hz, 2.8 A)
Item
Specifications
20/21 ppm 25/26 ppm

Kyocera FS-1060DN Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1800 x 600 DPI
Time to first page (black, normal)	7.5 s
Print speed (black, normal quality, A4/US Letter)	26 ppm
Printing colors	Black
Maximum duty cycle	15000 pages per month
Number of print cartridges	1
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols (IPv4)	TCP/IP
Processor model	ARM926EJ
Maximum internal memory	- MB
Sound pressure level (printing)	50 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Total number of input trays	2
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Labels, Plain paper, Pre-Printed, Recycled paper
Paper tray media weight	60 - 220 g/m²
ISO A-series sizes (A0...A9)	A4, A5
Maximum ISO A-series paper size	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage	220 V
AC input frequency	50 Hz
Power consumption (printing)	134 W
Product color	Black, White
Networking features	Fast Ethernet
Networking standards	IEEE 802.3, IEEE 802.3u
Compatible operating systems	Windows Vista 32/64 bit\\r Windows XP 32/64 bit\\r Windows 7 32/64 bit\\r Windows Server 2003\\r Windows Server 2008 32/64 bit\\r Mac OS X

Weight and Dimensions

Dimensions (WxDxH)	358 x 276 x 241 mm
