Kyocera FS-1060DN User Manual

2M2/2M3
1-4-16
(5)
Duplex solenoid
does not operate.
(25/26 ppm model
only)
1. Defective connector
cable or poor con-
tact in the connector.
Reinsert the connector. Also check for continuity within the
connector cable. If none, replace the cable.
Duplex solenoid and relay PWB (YC2)
Relay PWB and main PWB (YC14)
2. Defective solenoid. Replace the duplex solenoid.
3. Defective PWB. Replace the relay PWB or main PWB and check for correct
operation (see page 1-5-7).
(6)
Eraser lamp does
not turn on.
1. Defective connector
cable or poor con-
tact in the connector.
Reinsert the connector. Also check for continuity within the
connector cable. If none, replace the cable.
Eraser lamp PWB and main PWB (YC20)
2. Defective Eraser
lamp.
Replace the Eraser lamp PWB.
3. Defective PWB. Replace the main PWB and check for correct operation
(see page 1-5-7).
(7)
A paper jam in the
paper feed/convey-
ing section or fuser
section is indi-
cated when the
power switch is
turned on.
1.
A piece of paper torn
from paper is caught
around registration
sensor or d
uplex sen-
sor.
Check visually and remove it, if any.
2. Defective sensor. Replace the
registration sensor or duplex sensor.
(8)
Attention indicator
is lit when the front
and rear cover is
closed.
1. Defective connector
cable or poor con-
tact in the connector.
Reinsert the connector. Also check for continuity within the
connector cable. If none, replace the cable.
Power source PWB (YC103) and main PWB (YC12)
2. Defective switch. Check for continuity across the cover switch. If there is no
continuity when the cover switch is on, replace the power
source PWB (see page 1-5-7).
3. Failure of improper
controller unit
installation.
Check that the cover open-close lever A turns on the cover
switch when the front and rear covers are closed.
If it won’t turn on when covers are closed, re-seat the con-
troller unit.
Problem Causes Check procedures/corrective measures

Kyocera FS-1060DN Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1800 x 600 DPI
Time to first page (black, normal)	7.5 s
Print speed (black, normal quality, A4/US Letter)	26 ppm
Printing colors	Black
Maximum duty cycle	15000 pages per month
Number of print cartridges	1
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols (IPv4)	TCP/IP
Processor model	ARM926EJ
Maximum internal memory	- MB
Sound pressure level (printing)	50 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Total number of input trays	2
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Labels, Plain paper, Pre-Printed, Recycled paper
Paper tray media weight	60 - 220 g/m²
ISO A-series sizes (A0...A9)	A4, A5
Maximum ISO A-series paper size	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage	220 V
AC input frequency	50 Hz
Power consumption (printing)	134 W
Product color	Black, White
Networking features	Fast Ethernet
Networking standards	IEEE 802.3, IEEE 802.3u
Compatible operating systems	Windows Vista 32/64 bit\\r Windows XP 32/64 bit\\r Windows 7 32/64 bit\\r Windows Server 2003\\r Windows Server 2008 32/64 bit\\r Mac OS X

Weight and Dimensions

Dimensions (WxDxH)	358 x 276 x 241 mm
