Kyocera FS-C5150DN

2KT/2KV
1-5-6
5. Open the memory cover and then
remove it.
Figure 1-5-8
6. Open the waste toner cover.
7. Push the lock release button and then
remove the waste toner box.
Figure 1-5-9
Memory cover
Waste toner box
Waste toner
cover
Lock release button
