Kyocera FS-C5150DN

2KT/2KV
1-5-11
3. Remove the top cover (see page 1-5-3).
4. Remove the right rear cover, right cover
and right lower cover (see page 1-5-5).
5. Remove the left rear cover, left cover
and left lower cover (see page 1-5-8).
6. Release four hooks and then remove
the inner cover.
Figure 1-5-17
Inner cover
Inner cover
Hook
Hook
Hook
Hook
