Kyocera FS-C5150DN

To Next Page

To Previous Page

2KT/2KV

1-5-15

4. Remove the paper feed roller unit.

5. Check or replace the paper feed roller

unit and refit all the removed parts.

Figure 1-5-21

Paper feed

roller unit
