Kyocera FS-C5150DN

To Next Page

To Previous Page

2KT/2KV

1-5-22

4. Open the RFID holder.

Figure 1-5-31

5. Slide the shutter forward and seal the

toner inlet.

6. Remove the screw.

Figure 1-5-32

RFID holder

Screw

Shutter
