Kyocera FS-C5150DN - Page 126

2KT/2KV
1-5-30
7. Open the bracket.
8. Slide the plate. Release four hooks and
then remove the plate.
Figure 1-5-43
9. Remove the screw and then remove the
fuser wire cover.
Figure 1-5-44
Plate
Bracket
Hook
Hook
Hook
Hook
Screw
Fuser wire cover
