Kyocera FS-C5150DN

2KT/2KV
2-1-7
Figure 2-1-7 Paper conveying section block diagram
EPWB
RYPWB
MPFS
RS
RCL
REGCLDRN
YC3-13
MCL
MIDCLDRN
YC3-11
MP
FCL
MPFCLDRN
YC3-1
FEMOTRDYN
YC3-6
MPFJAM
YC9-18 YC4-2
REGPAP
YC18-3
FEMOTCLK
YC3-7
FEMOTREN
YC3-8
5
4
3
PFM
