Kyocera FS-C5150DN Service Manual

2KT/2KV
2-1-9
Figure 2-1-9 Drum section block diagram
DRRPWB
EPWB
HVPWB
DRPWB-K
CL-K
ERASECDR ERASEMDR ERASEKDR EECLK EEDATA ERASEYDR
YC34-2 YC34-4 YC34-6 YC34-8
YC34-10 YC34-12
YC1-2 YC1-4 YC1-6 YC1-8 YC1-10 YC1-12
EECLK ERASEKDR
ERASEKDR
ERASEMDR
EEDATA DA0 DA1 EEDATA DA0 DA1
YC2-2 YC2-3 YC2-4 YC2-7 YC2-8 YC3-2 YC3-3 YC3-4 YC3-7 YC3-8
CL-M
EEPROM
DRPWB-M
EECLK ERASEMDR
EEPROM
ERASECDR
EEDATA DA0 DA1
YC4-2 YC4-3 YC4-4 YC4-7 YC4-8
CL-C
DRPWB-C
EECLK ERASECDR
EEPROM
ERASEYDR
EEDATA DA0 DA1
YC5-2 YC5-3 YC5-4 YC5-7 YC5-8
Main chager high voltage Y Main chager high voltage C Main chager high voltage M Main chager high voltage K
Drum
unit Y
Drum
unit C
Drum
unit M
Drum
unit K
CL-Y
DRPWB-Y
EECLK ERASEYDR
EEPROM
MOTRDYN
YC13-2
SPEEDSEL
YC13-3
MOTCLK
MOTEN
YC13-4
YC13-5
6
5
4
3
DRM

Kyocera FS-C5150DN Specifications

General

Wi-Fi	No
Network ready	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	23 ppm
Maximum duty cycle	50000 pages per month
Number of print cartridges	4
Memory type	DDR
Memory slots	1
Processor model	PowerPC 464
Maximum internal memory	1280 MB
Sound power level (standby)	50 dB
Display	-
Total input capacity	250 sheets
Total output capacity	- sheets
Multi-Purpose tray input capacity	50 sheets
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Photo paper, Pre-Printed, Recycled paper
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Bond paper, Letterhead, Recycled paper
Maximum ISO A-series paper size	A4
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	2
Mac operating systems supported	Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 2000, Windows 2000 Professional, Windows 7 Home Premium, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (printing)	- W

Weight and Dimensions

Dimensions (WxDxH)	391 x 523 x 371 mm
