Kyocera FS-C5150DN Service Manual

2KT/2KV
2-3-15
YC7 1 GND - - Ground
Connected to
laser scanner
unit KM
2 +3.3V3 O 3.3 V DC 3.3 V DC power to APCPWB-M
3 PDMN I 0/3.3 V DC (pulse) Horizontal synchronizing signal
4 VDOMP O LVDS APCPWB-M video data signal (+)
5 VDOMN O LVDS APCPWB-M video data signal (-)
6 GND - - Ground
7 +3.3V3 O 3.3 V DC 3.3 V DC power to APCPWB-K
8 PDKN I 0/3.3 V DC (pulse) Horizontal synchronizing signal
9 VDOKP O LVDS APCPWB-K video data signal (+)
10 VDOKN O LVDS APCPWB-K video data signal (-)
YC8 1 I2CSDA I/O 0/3.3 V DC (pulse) EEPROM data signal
Connected to
relay PWB
2 GND - - Ground
3 I2CSCL O 0/3.3 V DC (pulse) EEPROM clock signal
4 RESETN O 0/3.3 V DC Reset signal
5 SCKN O 0/3.3 V DC (pulse) Serial communication clock signal
6 SO I 0/3.3 V DC (pulse) Serial communication data signal input
7 SI O 0/3.3 V DC (pulse) Serial communication data signal output
8 SDIR I 0/3.3 V DC Serial communication direction change
signal
9 SBSY I 0/3.3 V DC Serial busy signal
10 EGIRN I 0/3.3 V DC Engine interruption signal
11 VSYNC I 0/3.3 V DC (pulse) Vertical synchronizing signal
12 +3.3V1 O 3.3 V DC 3.3 V DC power to RYPWB
13 GND - - Ground
YC9 1 +5V1 - 5 V DC 5 V DC power to OPPWB
Connected to
operation
panel PWB
2 FPRSTN O 0/3.3 V DC OPPWB reset signal
3 +3.3V1 O 3.3 V DC 3.3 V DC power to OPPWB
4 FPTXD O 0/3.3 V DC (pulse) OPPWB transmission data
5 FPRXD I 0/3.3 V DC (pulse) OPPWB received data
6 GND - - Ground
Connector Pin Signal I/O Voltage Description

Kyocera FS-C5150DN Specifications

General

Wi-Fi	No
Network ready	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	23 ppm
Maximum duty cycle	50000 pages per month
Number of print cartridges	4
Memory type	DDR
Memory slots	1
Processor model	PowerPC 464
Maximum internal memory	1280 MB
Sound power level (standby)	50 dB
Display	-
Total input capacity	250 sheets
Total output capacity	- sheets
Multi-Purpose tray input capacity	50 sheets
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Photo paper, Pre-Printed, Recycled paper
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Bond paper, Letterhead, Recycled paper
Maximum ISO A-series paper size	A4
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	2
Mac operating systems supported	Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 2000, Windows 2000 Professional, Windows 7 Home Premium, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (printing)	- W

Weight and Dimensions

Dimensions (WxDxH)	391 x 523 x 371 mm
