Kyocera FS-C5150DN Service Manual

2KT/2KV
2-3-17
YC10 A19 RESETN O 0/3.3 V DC Reset signal
Connected to
KUIO slot
B19 VOLTDETECT - - Ground
A20 D15 I/O 0/3.3 V DC (pulse) Data bus signal
B20 D14 I/O 0/3.3 V DC (pulse) Data bus signal
A21 GND - - Ground
B21 D13 I/O 0/3.3 V DC (pulse) Data bus signal
A22 D12 I/O 0/3.3 V DC (pulse) Data bus signal
B22 D11 I/O 0/3.3 V DC (pulse) Data bus signal
A23 D10 I/O 0/3.3 V DC (pulse) Data bus signal
B23 D9 I/O 0/3.3 V DC (pulse) Data bus signal
A24 D8 I/O 0/3.3 V DC (pulse) Data bus signal
B24 D7 I/O 0/3.3 V DC (pulse) Data bus signal
A25 GND - - Ground
B25 D6 I/O 0/3.3 V DC (pulse) Data bus signal
A26 D5 I/O 0/3.3 V DC (pulse) Data bus signal
B26 D4 I/O 0/3.3 V DC (pulse) Data bus signal
A27 D3 I/O 0/3.3 V DC (pulse) Data bus signal
B27 D2 I/O 0/3.3 V DC (pulse) Data bus signal
A28 D1 I/O 0/3.3 V DC (pulse) Data bus signal
B28 D0 I/O 0/3.3 V DC (pulse) Data bus signal
A29 GND - - Ground
B29 NC - - Not used
A30 NC - - Not used
B30 NC - - Not used
YC12 1 +24V1 O 24 V DC 24 V DC power to RFM
Connected to
right fan
motor
2 RFANDRN O 0/12/24 V DC RFM: Full speed/Half speed/Off
YC14 1 +24V1 I 24 V DC 24 V DC power from PSPWB
Connected to
power source
PWB
2 GND - - Ground
Connector Pin Signal I/O Voltage Description

Kyocera FS-C5150DN Specifications

General

Wi-Fi	No
Network ready	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	23 ppm
Maximum duty cycle	50000 pages per month
Number of print cartridges	4
Memory type	DDR
Memory slots	1
Processor model	PowerPC 464
Maximum internal memory	1280 MB
Sound power level (standby)	50 dB
Display	-
Total input capacity	250 sheets
Total output capacity	- sheets
Multi-Purpose tray input capacity	50 sheets
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Photo paper, Pre-Printed, Recycled paper
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Bond paper, Letterhead, Recycled paper
Maximum ISO A-series paper size	A4
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	2
Mac operating systems supported	Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 2000, Windows 2000 Professional, Windows 7 Home Premium, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (printing)	- W

Weight and Dimensions

Dimensions (WxDxH)	391 x 523 x 371 mm
