Kyocera FS-C5150DN Service Manual

2KT/2KV
2-3-19
Connector Pin Signal I/O Voltage Description
YC1 1 TNSENM O Analog TS-M detection voltage
Connected to
engine PWB
2 ERASECDR I 0/24 V DC CL-C: On/Off
3 TNSENK O Analog TS-K detection voltage
4 ERASEMDR I 0/24 V DC CL-M: On/Off
5 DLPTHERM O Analog DEVTH detection voltage
6 ERASEKDR I 0/24 V DC CL-K: On/Off
7 +3.3V2 I 3.3 V DC 3.3 V DC power from EPWB
8 EECLK I 0/3.3 V DC (pulse) EEPROM clock signal
9 GND - - Ground
10 EEDATA I/O 0/3.3 V DC (pulse) EEPROM data signal
11 TNSENY O Analog TS-Y detection voltage
12 ERASEYDR I 0/24 V DC CL-Y: On/Off
13 TNSENC O Analog TS-C detection voltage
YC2 1 GND - - Ground
Connected to
drum PWB K
2 EECLK O 0/3.3 V DC (pulse) EEPROM clock signal
3 ERASEKDR O 0/24 V DC CL-K: On/Off
4 EEDATA I/O 0/3.3 V DC (pulse) EEPROM data signal
5 N.C. - - Not used
6 +3.3V2 O 3.3 V DC 3.3 V DC power to DRPWB-K
7DA0 -- Not used
8DA1 -- Not used
YC3 1 GND - - Ground
Connected to
drum PWB M
2 EECLK O 0/3.3 V DC (pulse) EEPROM clock signal
3 ERASEMDR O 0/24 V DC CL-M: On/Off
4 EEDATA I/O 0/3.3 V DC (pulse) EEPROM data signal
5 N.C. - - Not used
6 +3.3V2 O 3.3 V DC 3.3 V DC power to DRPWB-M
7 DA0 - - Ground
8DA1 -- Not used
YC4 1 GND - - Ground
Connected to
drum PWB C
2 EECLK O 0/3.3 V DC (pulse) EEPROM clock signal
3 ERASECDR O 0/24 V DC CL-C: On/Off
4 EEDATA I/O 0/3.3 V DC (pulse) EEPROM data signal
5 N.C. - - Not used
6 +3.3V2 O 3.3 V DC 3.3 V DC power to DRPWB-C
7DA0 -- Not used
8 DA1 - - Ground

Kyocera FS-C5150DN Specifications

General

Wi-Fi	No
Network ready	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	23 ppm
Maximum duty cycle	50000 pages per month
Number of print cartridges	4
Memory type	DDR
Memory slots	1
Processor model	PowerPC 464
Maximum internal memory	1280 MB
Sound power level (standby)	50 dB
Display	-
Total input capacity	250 sheets
Total output capacity	- sheets
Multi-Purpose tray input capacity	50 sheets
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Photo paper, Pre-Printed, Recycled paper
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Bond paper, Letterhead, Recycled paper
Maximum ISO A-series paper size	A4
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	2
Mac operating systems supported	Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 2000, Windows 2000 Professional, Windows 7 Home Premium, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (printing)	- W

Weight and Dimensions

Dimensions (WxDxH)	391 x 523 x 371 mm
