2T6/2T7/2T8/2T9
1-5-14
6. Pull the connector out.
7. Release the lock lever and then remove
the developer unit upward.
8. Check or replace the developer unit and
refit all the removed parts.
Figure 1-5-22
Developer unit
Connector
Connector
Lock lever
