Kyocera PF-3100 - Installing the Toner Container

2T6/2T7/2T8/2T9
1-2-4
(60/50/45 ppm model only)
4. Open the top cover.
5. Remove the tape and the spacer.
Figure 1-2-5
1. Open the top cover.
2. Remove the container label by pulling
forwards.
Caution: Check the contents of the
container label and remove a container.
Figure 1-2-6
Tape
Top cover
Spacer
Installing the toner container
Container label
Top cover
