2T6/2T7/2T8/2T9
1-1-9
(3) Internal Components
Figure 1-1-3
15
16
19
26
22
23
24
25
18
20
21
17
15. Top Cover
16. Toner Container
17. Lock Lever
18. Front Cover
19. Duplex Front Cover
20. Developer Unit
21. Registration Roller
22. Paper Width Guides
23. Paper Width Adjusting Tab
24. Paper Length Guide
25. Paper Length Adjusting Tab
26. Paper Size Dial
