Long type and helpful to access
the distant measurement spot
Thin tip metal parts
5. Accessories
● Test leads
(1) Test probe MODEL7196A with remote control switch (red)
Fig. 5-1
(2) CAT II standard prod MODEL8072 (3) Extension prod MODEL8017
…1 pce …1 pce
Fig. 5-2 Fig. 5-3
* These metal tips are for MODEL7196A.
(5) Black cord with banana plugs at both ends
Fig. 5-4
+
(6) Alligator clip (7) Flat test bar
Fig. 5-5 Fig. 5-6
(8) L-shaped probe MODEL7243 (9) Hook type prod MODEL8016
(Optional accessory) (Optional accessory)
* Attached and used with MODEL7196A.
Fig. 5-8
Fig. 5-7
Changeable metal tips are available for MODEL7196A.
+
(4) A set of test leads with alligator clip MODEL7244A
To hook the probe on a conductor
