If the washer passed all tests, continue to Section 5: Performance Features to become
familiar with the features and controls of the glassware washer.
High Elevation Installations
If the washer is installed at an elevation above 2000 meters (6561 feet), the maximum
programmable temperature set point MUST be changed from 93
o
C to 88
o
C. See
Section 5: Calibration – Setpoints for instructions to make this change.
HELP
AUTO
TEST
PASS/
FAIL
DIAGNOSTICS
Figure 4-9
