76
Loading a Glassware Holder
Press the glassware into the holder; the fingers should spring out and grip the
glassware.
It is normal for the clamps to deform if large glassware is inserted into the Holder
and the washer is operated at high temperature. Do not use with glassware over
2.5 inches in diameter as damage to holder may occur.
To reduce the possibility of trapping water in the glassware, the horizontal leg of
the spring clip should be positioned on the bottom side of the holder.
The holder may be raised or lowered by squeezing the spring clip on the bottom
of the holder and then sliding the holder up or down.
For best results, do not allow the glassware to rest directly on top of the spindle.
Glassware should be loaded so that it does not touch during a wash cycle. To reduce
noise and glass breakage, be certain that glassware is secured.
Detergent Dispenser (Soap Cup)
Your Glassware Washer is equipped with a detergent dispenser (also referred to as a
Soap Cup) inside the door, which contains a Main Wash Cavity and a Neutralizing
Solution (Rinse-Aid) Reservoir as shown in Fig. 7-3. In addition, the dispenser door
provides a depression (Pre-Wash Detergent Cavity) where detergent may be added for
use during the first Wash of the cycle.
MAIN WASH
CAVITY
RINSE AID
FILL
DETERGENT DOOR
RELEASE
RINSE AID
DOOR
PRE-WASH
DETERGENT
CAVITY
Figure 7-3
