44
View a Program
From the Program Screen touch the program you wish to view; the line will be
highlighted. If this is the correct program, press [View] (for a locked program) or [Edit]
(for an unlocked program). The program parameters will be displayed. See Fig. 6-6.
SEGMENT TIME(min) TEMP (°C/°F)
H2O
SOURCE
DOOR CUP / AUTO
DETERGENT
(IF INSTALLED)
DOOR CUP /
AUTO RINSE-
ID
(IF INSTALLED)
Delay 0-720
Pre-Wash 0-40 25-93 / 77-200 Hot or Pure D-Cup* / 0-40 ml
Steam 0-20
Wash 1 0-40 25-93 / 77-200 Hot or Pure D-Cup* / 0-40 ml
Wash 2^ 0-40 25-93 / 77-200 Hot or Pure D-Cup* / 0-40 ml
Rinse 1-8 0-40 25-93 / 77-200 Hot or Pure 6ml** / 0-40 ml
Dry 0-240 25-80 / 77-176
Auto Unlock ON/OFF
^ Factory Programs with Wash 2 are only available when Auto Detergent Dispense Kit is installed.
* Detergent dispensed from the Door Cup can only be specified in one (1) Pre-Wash or Wash segment.
** Rinse-Aid dispensed from the Door Cup can be dispensed in 1 mL increments up to 6 mL. Rinse-Aid can only be dispensed from the
Door Cup in one (1) Rinse segment.
Figure 6-6
Figure 6-5
