75
FlaskScrubber Spindle Rack
The FlaskScrubber Glassware Washer is equipped with a lower spindle rack and
glassware holders. The FlaskScrubber spindle rack is designed for narrow-necked
glassware such as volumetric flasks, Erlenmeyer flasks, graduated cylinders, Kjeldahl
flasks, test tubes, BOD bottles and digestion tubes.
For versatility, two sizes of spindles are provided with the washer: (36) 0.25" (6.35 mm)
OD and (10) 0.125" (3.18mm) OD spindles. Several optional inserts can be placed in
the rack to support various configurations of glassware. See Section 9: Accessories &
Consumables for available options. Each spindle, or spindle arm, can be removed with
the supplied wrench and replaced with plugs included with the washer. The spindle
arms can be angled to enable washing up to 24” long items, such as graduated
cylinders. Optional top racks are available for the FlaskScrubber to expand the washer’s
capacity to accommodate many types of glassware. An Upper Spindle Rack with 36
spindles and slides (Catalog Number 4668500) is available.
Loading Glassware into the FlaskScrubber
Glassware Holders are supplied with each FlaskScrubber. These holders enable you to
position glassware directly over the FlaskScrubber spindles. See Fig. 7-2.
SPRING CLIP
GLASSWARE
HOLDER
LOWER
SPINDLE
RACK
Figure 7-2
