6: CleanWorks™ Operating System
The Glassware Washer operating system provides clear status information on the touch
screen and user control with the keypad (Fig. 6-1). Read this section along with Section
7: Using Your Glassware Washer to fully understand the features and controls of this
product.
Control Panel
Touch Screen Display
The touch screen displays system operating parameters, set-up parameters and alarm
messages. All user-control interface will take place via the touch screen.
Open Button
If the glassware washer is powered and not in operation pressing this button will unlatch
the door. Pressing this button during a wash cycle will prompt for user confirmation to
pause the cycle and then open the door. Once confirmed, the cycle will pause for 7
seconds to allow the wash pump to stop and then unlatch the door lock.
On / Standby LED Indicator
Blue LED indicator light designates the current status of the system.
o 1 flash per second = Initial power up (loading operating system)
o Slow pulse = Touch screen in low power mode (screen timeout)
o ON = Unit is plugged in and touch screen is in active mode
o Off = Unit is unplugged
OPEN BUTTON
ON/STANDBY
LED INDICATOR
TOUCH SCREEN
DISPLAY
Figure 6-1
