Chapter 8: Troubleshooting

Product Service 1-800-522-7658

117

Original instructions

PROBLEM

CAUSE

CORRECTIVE ACTION

Electrical duplex

outlets no longer

have power

Wires not connected

or faulty duplex.

Check wire connection or replace

duplex.

Circuit breakers

tripped in building

electrical supply.

Reset circuit breakers.

Service valves no

longer operate

Faulty building

supply.

Inspect building supply shut off valves

and appropriate pressures below the

recommended 40 PSI.

Valve no longer

operates.

Replace valve and check for leaks.

Supply line or outlet

line has leaks.

Inspect line for leaks and fix any

leaking plumbing connections.
