Operating the A
UTOMIZER
TM
R
ECYCLER
67
N
OTE
:
Make sure to roll up hoses around fitting holder on the swivel arm after each use. This will
prevent hydraulic hoses from falling when the vehicle is moving (see
Figure
4-29)
Figure 4-29
Hydraulic hoses rolled up
Warning!
Do not drive the vehicle if the swivel arm is not folded and locked along the hopper.
Warning!
Disconnect and roll up both hydraulic supply hoses after each use.
71
73
