2244 VV PPAANNEELL
It groups the different 24 V functions onboard: lighting, grey water
pumps, electric heads, deck wash pump (optional extra), refrigeration
units, pressure water pumps, inverters, diesel oil transfer pump.
BBIILLGGEE PPUUMMPP PPAANNEELLSS
The four small panels situated near the 110 V - 220 V panel control the
bilge pumps.
The switch on the left makes three positions possible: automatic start,
OFF and manual operation. The switch on the right makes possible to
stop the alarm.
MMUULLTTIIFFUUNNCCTTIIOONN SSCCRREEEENN
A touch screen on the chart table gives access to :
- The jauges of the fresh water and fuel tanks.
- The consumption (amperes) and voltage (volts) of the batteries.
- The control of the navigation lights, anchor lights, deck lights...
- The switching on of the electronics.
- The switching on of all the lightings on board.
- The start of the fuel transfer pump.
ELECTRICITY
ELECTRICITY
4
LAGOON 62O
49
RECOMMENDATION
We recommend that you keep the bilge pumps in the
automatic start position with alarm.
We advise you to carry out a test of the bilge pumps
each time before you put out to sea.
 4.1 24 V system
z
BATTERIES
The battery bank supplies the boat with 24 V and is located in the
service room of the foredeck.
The whole 24 V circuit is energized when you turn to the ON position
the manual cut-out under the chart table.
z
BATTERY RECHARGING
You recharge the battery bank with a coupled alternator (110 Ah / 24 V) or
a battery charger (220 Ah / 24 V).
BATTERY CHARGERS (OPTIONAL EXTRA)
The battery chargers are located in the service room of the foredeck.
The 110 V - 220 V / 24 V chargers recharge the domestic batteries.
OPERATION
The battery chargers can be used with the shore power socket #1 or
the operating generator.
Turn the HIGH LOAD selector to SHORE or GENERATOR.
Make sure their circuit breakers on the electrical panel are properly
set.
Nota : the battery chargers can remain in operation even when the
boat is not energized in 24 V.
z
CONTROL OF THE 24 V CONSUMING APPLIANCES
The control of the 24 V consuming appliances is distributed between
three areas :
