RECAPITULATION OF THE 12 V AND 24 V COMPONENTS
ELECTRICITY
4
LAGOON 62O
59
CHARGE AAND EELECTRIC CCONVERSION
220 V or 110 V / 24 V - 100 Ah Charger As optional extra : recharge of the 24 V service battery bank (refer to 110 V / 220 V recapitulation)
220 V / 12 V charger (3 connections) With the optional generator to recharge the 12 V generator battery and the two 12 V engine batteries
24 V - 110 Ah coupled alternator Recharge in 24 V of the service battery bank
24 V / 12 V electronic inverter With the electronics
24 V / 12 V car-radio inverter With the car-radio optional extra
BATTERIES // CCONSUMING AAPPLIANCES
24 VV ddirect ccurrent Voltage SStarti
ng uup PProtection
Service batteries 24 V (420 Ah as standard, 840 Ah as optional extra)
Recharge of the service batteries by a coupled alternator (24 V) per engine + 220 V / 24 V - 100 Ah chargers (optional extra)
Navigation electronics 24 V Multifunction screen
Utility lighting 24 V Multifunction screen
Navigation light 24 V Multifunction screen
Lighting 24 V Multifunction screen
Fridge in cockpit 24 V 24 V Electrical panel 24 V Electrical panel
Fridge on fly 24 V 24 V Electrical panel 24 V Electrical panel
Electric heads 24 V 24 V Electrical panel 24 V Electrical panel
Deck wash pump 24 V 24 V Electrical panel 24 V Electrical panel
Winches 24 V 24 V Domestic Electricity room
Windlass (directly on the batteries) 24 V 24 V Domestic Electricity room
Capstans 24 V 24 V Domestic Electricity room
Davits / Tenderlift 24 V
Gangway 24 V : hydraulic pump
Bow thruster 24 V : hydraulic pump
12 VV ddirect ccurrent VVoltage
Engine start batteries (12 V - 50 Ah) x 2
Recharge of engine battery by engine alternator + 220 V / 12 V charger
Generator start battery (12 V - 50 Ah) x 1
Recharge of generator battery by generator alternator + 220 V / 12 V charger
Electronic control of engine 12 V connected on engine start battery once "on"
Cameras
Hub (network terminal) 12 V
VHF powered by a 24 V / 12 V inverter
Car-radio
