Lagoon 620 - Place of the Engines; Coupling Circuit Breaker

96
PROPULSION
PLACE OF THE ENGINES
LAGOON 62O
1 - Fuel tanks.
2 - Fuel closing pull handle.
3 - Sea water filter.
4 - Fuel filter.
5 - Engine water inlet valve .
6 - Engine.
7 - Expansion tank.
8 - Diesel oil tank fillers.
9 - Engine starting panel.
10 - E-key.
Each hull has the same components.
Nota : each valve in the boat is identified.
COUPLING CIRCUIT
BREAKER
1
4
6
3
5
2
7
8
Nota: the same layout can be observed
in the other versions.
9
10
