Lagoon 620 - V Automatic Fuses; 24 V Fuses - Electric Box in Admiships Cabin to Port; 24 V Fuses - Electric Box in Admiships Cabin to Starboard

24 V AUTOMATIC FUSES
ELECTRICITY
4
LAGOON 62O
57
24 V FUSES - ELECTRIC BOX IN
ADMISHIPS CABIN TO PORT
24 V FUSES - ELECTRIC BOX IN
ADMISHIPS CABIN TO STARBOARD
The fuses of some elements are in electric boxes
located behind the headboards in the aft cabin to
starboard and in the admiships cabin to port (double
bed version) or at the back of the cabinet between the
two beds (bunk bed version).
These elements are energized using the 24 V general
cutout.
Nota : the LIGHTING fuses on the electrical panel are
only for a part of the saloon lighting and outside
lightings (bimini, spreaders, etc.).
