ELECTRICITY
ELECTRICITY
4
LAGOON 62O
63
z
CONTROL OF THE 110 V - 220 V CONSUMING APPLIANCES
111100 VV - 222200 VV SSEELLEECCTTIIOONN PPAANNEELL
This panel has 3 switches which enable you to choose the supply
source for the different 110 V - 220 V consuming appliances on board.
CONFORT - UTILITY SELECTOR :
- Allows the use of the appliances grouped together on the CONFORT
- UTILITY bus using 110 V - 220 V current coming from the generator,
shore or inverter (automatic start of the inverter when it is selected).
PUISSANCE AC - AC HIGH LOAD SELECTOR :
- Allows the use of the appliances grouped together on the
PUISSANCE AC - AC HIGH LOAD bus of the 110 V - 220 V protection
electrical panel, using 110 V - 220 V current coming from the
generator or shore.
CLIMATISATION - AIR COND SELECTOR :
- Allows the use of air conditioning, on the CLIMATISATION - AIR COND
bus, using 110 V - 220 V current coming from the shore power socket
# 2 or generator.
111100 VV - 222200 VV PPRROOTTEECCTTIIOONN PPAANNEELL
This area groups together 3 buses of circuit-breakers of the 110 V -
220 V appliances and equipments. Each of these buses has a major
circuit breaker and several individual circuit breakers. This panel
allows you to choose the supply source of the consuming appliances.
CONFORT - UTILITY :
- Groups together the 110 V - 220 V consuming appliances that are
likely to be supplied by the inverter.
PUISSANCE AC - AC HIGH LOAD :
- Groups the heavy 110 V- 220 V consuming appliances that need the
generator start up or shore power suply.
CLIMATISATION - AIR COND :
- Attributed to air conditioning for the starting up of the system.
PPAANNEELL OOFF TTHHEE CCIIRRCCUUIITT BBRREEAAKKEERRSS OOFF TTHHEE HHOOUUSSEEHHOOLLDD AAPPPPLLIIAANNCCEESS
The 110 V - 220 V kitchen appliances have a dedicated circuit breaker
panel.
This panel is located under the cockpit companionway in the galley
(version with the galley at the aft of the port hull), and behind a hatch
at the back of the aft cabinet between the two berths of the central
cabin in the port hull (version with galley in the saloon).
Nota : all the circuit breakers of the 110 V - 220 V system are
differential circuit breakers. Therefore you do not need fuses for this
system on board.
