WASHING MACHINE - DISHWASHER
ON BOARD UTILITY
LAGOON 62O
1 - Washing machine.
2 - Dishwasher.
3 - Water supply manifold.
4 - Washing machine / dishwasher breakers.
Nota : the manifold is located under the sink
and distributes water to sink, refrigerator,
dishwasher and washing machine.
WASHING MASCHINE /
DISHWASHER BREAKERS
MANIFOLD DISTRIBUTES
HOT / COLD WATER
Galley / hull version
Galley / saloon version
Galley / hull version
Galley / saloon version
1
2
4
2
3
1
3
4
