Lagoon 620 - Recapitulation # 1; 110 V - 220 V Components

66
RECAPITULATION # 1 / 110 V - 220 V COMPONENTS
ELECTRICITY
LAGOON 62O
GENERATOR
Generator power 17,5 kva European Version The generator gives 100% of its power in 220 V - 50 Hz (AIR CONDITIONING, UTILITY and 220 V HIGH LOAD buses)
Generator power 17,5 kva US Version The generator gives 75% of its power in 220 V (AIR COND and 220 V HIGH LOAD buses)
The generator gives 25% of its power in 110 V (UTILITY and 110 V HIGH LOAD buses)
SHORE PPOWER SSOCKET
HIGH LOAD Shore power socket
European Version A 50 Ah simple shore power socket - connection in the port aft transom extension (220 V - 50 Hz)
AIR COND Shore power socket European Version A 50 Ah simple shore power socket - connection in the port aft transom extension (220 V - 50 Hz)
HIGH LOAD shore power socket US Version Utilisation of the two 110 V phases to supply 220 V power on board.
ELECTRIC DDISTRIBUTION
UTILITY BUS 110 V or 220 V Supplied by generator, shore or inverter (optional extra 1 or 2)
HIGH LOAD BUS 110 V or 220 V Supplied by generator or shore
AIR COND BUS 110 V or 220 V Supplied by generator or shore
CHARGE AAND EELECTRIC CCONVERSION
220 V or 110 V / 24 V - 100 Ah charger Optional : recharge of the service bank by generator or shore
220 V / 12 V charger (3 connexions) Automatically comes with the optional generator to recharge the 12 V battery, the generator and the two 12 V engine batteries
Standard inverter 24 V / 220 V - 1500 Va
Utility inverter OPTIONAL EXTRA 24 V / 220 V - 5000 Va
