SmartShop|Maker Owner’s Manual
27
3. Click F3 MDI Input.
4. Click F1 Confirm.
5. Type in the Tool number.
6. Click Main.
7. Click on AutoTool.
8. Click Cycle Start.
9. Repeat with each tool as necessary.
6.4.2 Manual TTO Setup with the Worktable
To manually measure the tool length using the worktable:
1. Load a tool with a flat bottom router bit.
2. Jog the Z-Axis until the tip of the tool is just above the top of the spoil board.
3. Step down in slow mode while turning the router collet by hand in the reverse direction. When
you feel pressure, stop jogging down. It may be helpful to lower the bit on a piece of paper
and stop when the paper can no longer be moved.
DANGER
DO NOT turn the router bit by hand as it is sharp and could
cause injury.
4. Set as the tool height.
NOTE
The machine “B” parameter setting will not be present unless
it is selected
