SmartShop|Maker Owner’s Manual
31
1. Rapid - Fast moving machine X+Y+Z+B+ X-Y-Z-B-: In Jog mode, move the machine
manually.
2. Vacamp1 – Vacuum Pump1 On. Press again to turn off the pump.
3. Vacamp2 – Vacuum Pump2 On. Press again to turn off the pump.
4. AutoTool – Select to enter the appropriate tool number in MDI mode.
5. Brusher – Move the Spindle Brush Up and Down.
6. Spindle Preheating – Preheat the spindle. This may be necessary if the machine has not
been in use for a significant period of time.
7. SP. CW – Spindle Clockwise.
8. SP. Stop – Spindle Stop.
The operator can jog the machine in the desired direction.
1. Click on the Machine Jog button to enter.
2. Control the movement with axes directional keys --『 X+,X-,Y+,Z+,Z- 』.
CAUTION
Click on the G0- key or reduce the speed before entering this
mode. If it is safe, use the G0+ button to increase the speed.
6.10.2 Idle Speed Adjustment
Press G0- or G0+ to decrease the increase the speed spindle speed adjustment.
6.11 Multiple Pulse Generator (MPG) Handwheel
The operator can move the axes by spinning the MPG Handwheel.
Select the MPG Mode to define the axis, direction, and speed.
1. Turn the handwheel in the clockwise (CW) direction, the machine will move in the positive
direction.
