SmartShop|Maker Owner’s Manual
36
7.2 Running the Program
CAUTION
Before performing a fly cut program, AutoTool must be turned
off or damage to the project material, worktable, or machine
may result.
1. Click F2 Program.
2. Click F8 File Manager.
3. Highlight and click the program file from the list.
4. Click F5 Execute.
5. Click Cycle Start to run the program.
6. Click F4 Monitor to monitor the execution of the program on the screen.
7.3 Running a Flycut Project
Before beginning this operation, load a flycut bit into the spindle (see Section 5.6). Refer to Figure
6-1: Main Screen for button locations.
1. Click Home.
2. Click CycleStart.
3. Click Jog.
4. Press Vacamp1 and Vacamp2 to tun on the vacuums.
5. Click MPG.
6. Click Brusher to raise the dust hood.
7. On the MPG controller, select the “Z” axis and X10 speed (refer to Section 6-11).
8. Complete a manual Tool Touch Off (Refer to Section 6.4.2)
9. Click F3 Offset/Setting (refer to Figure 6-3).
10. Click F2 Toolset.
