SmartShop|Maker Owner’s Manual
28
NOTE
Do not delete the disk C and network on the D disk.
6.5 External Shift
To adjust for spoil board thickness, first perform a Tool Touch Off as described in Sections 6.4.1
and 6.4.2. The External Shift adjustment can be performed by one of the following methods.
6.5.1 Adjust External Shift with Manual Measurement
Measure the spoil board with calipers or a tape measure and record the measurement.
1. Click MDI.
2. Click F3 Offset/Settings.
3. Click F2 Tool Set.
4. Subtract the measured length from the geometry length.
5. Highlight the External Shift Geometry number.
6. Enter the new length and press Enter.
7. Click Cycle Start.
6.5.2 Adjust External Shift Using Tool Set
Lower the tool until it is touching the spoil board and record the machine length as indicated on
the Tool Set screen.
1. Click MDI.
2. Click F3 Offset/Settings.
3. Click F2 Tool Set.
4. Highlight the External Shift Geometry number.
5. Enter the new length and press Enter.
6. Click Cycle Start.
