LaMotte TC-3000 - Detector; Response Time; Signal Averaging; Sample Chamber

Detector: Turbidity: Photodiode, centered at 90°, maximum peak
550 nm, TC-3000e;
Photodiode, centered at 90° TC-3000i
Color: Photodiode
Chlorine: Photodiode
Light Source
Stabilization:
Automatic
Response Time: <5 seconds
Signal Averaging: Turbidity and color
Sample Chamber: Accepts 25 mm flat-bottomed test tubes
Sample: 10 mL in capped tube
Display: Graphic Liquid Crystal Display
Software: Data Logging: 4004 points
Auto Shut-off: 5, 10, 30 min, disabled
Calibration: Field adjustable, 2-points
Languages: English, French, Spanish, Japanese (Kana), Portuguese, Italian
Temperature: Operation: 0–50 °C; Storage: -40–60 °C
Operation Humidity
Range:
0–90 % RH, non-condensing
Auto Shutdown: 0, 5, 10 or 30 minutes
Power Source*: Battery Operation: 9 volt alkaline
Line Operation: Input: 100-240VAC/50-60Hz with imbedded
IEC socket (2 pin)
Output: 9VDC REG 1.2A with 2.1 x 5.5 mm output plug center
positive
Battery Life: >250 tests, T C-3000e
>2500 tests, TC-3000i
(with signal averaging disabled)
Dimensions
(LxWxH):
8.5 x 16.2 x 16.7 cm; 3.4 x 6.4 x 2.6 inches
Weight: 339 g, 12 oz (meter only)
Serial Interface: RS232, 8 pin mDIN, 9600b, 8, 1, n
*CE Mark: The devise complies to the product specifications for the Low Voltage
Directive when furnished with the 100-240V AC Adapter (Code 1754).
SPECIFICATIONS 7
