Stray Light
The accuracy of readings on the TC 3000 should not be affected by stray light. Make
sure that the sample compartment lid is always fully closed when taking readings.
PC LINK
The TC-3000 may be interfaced with any Windows-based computer by using the
LaMotte SMARTLink 2 Program and Interface Cable (Code 1912-3 with 3.5 inch disk
or Code 1912-CD with compact disk). The program will store test information and
results in a database. The meter may also be interfaced with an RS232 serial printer,
using an interface cable (Code 1772) and setting the printer configuration to the
Output as described below.
Output
RS232 compatible, asynchronous serial, 9600 baud, no parity, 8 data bits, 1 stop bit.
Computer Connection
RS232 interface connection, 8 pin mini-DIN/9 pin F D-submin. (Order Interface
Cable Code 1772).
76 PC LINK
