SCS100/200/400 User Guide 6: Application Setup
Creating a User Account
2. To configure an external serial modem, attach the modem to one of the serial ports
and follow these steps:
a) Click the Modem link.
b) Click the Configure link for the port with the attached modem.
c) Select the modem type from the drop-down list.
d) If you want to enable authentication, check the Authenticate Users box.
e) Click the Update button.
3. To configure a PC card modem for the SCS200 or SCS400, insert the PC card
modem into the PC card slot and follow these steps:
a) Click the Modem link.
b) Click the Configure link next to port 3 (the PC card slot).
c) Leave the modem type as Generic (the default for a PC card modem).
d) If you want to enable authentication, check the Authenticate Users box.
e) Click the Update button.
Note: If you inserted a PC-card modem while the SCS was powered up, you
need to restart the SCS.
4. Specify an IP Pool address range for remote users:
6-10
