SCS100/200/400 User Guide 4: The SCS400
SCS400 PCC1 and PCC2 Card LED Functions
LED 802.11 Cards ATA Cards Modem Cards
Not lit No card in slot No card inserted No card inserted
Green solid Ready Ready Ready
Green blinking
Negotiating settings
with AP or ad-hoc peer
PC card not formatted n/a
Red solid PC card failure PC card failure PC card failure
Red blinking
PC card not read or
supported
PC card not read or
supported
PC card not read or
supported
Yellow solid Initialization in progress Initialization in progress Initialization in progress
Yellow blinking
Scanning for Access
Point (AP) or ad-hoc
peer
n/a Initialization problem
Specifications of the SCS400
Power
Screw terminal power jack 9-30 VDC
Power Cube Adapter
input
output
100-240 VAC US; 100-240 VAC international power cord
12 VDC
DC power input 9-30 5 VDC
Current 1.5 A @ 12 V
Power consumption 18 Watts max.
Temperature
Note: Rapid temperature changes may affect operation. Do not operate near
heating or cooling devices or areas that open to the outdoors.
Operating range 5° to 50° C (41° to 122° F)
Storage range -40° to 66° C (-40° to 151° F)
Max. temp change 20° C (36° F) per hour
Humidity
Operation 10% to 90% non-condensing
Ideal 40% to 60%
Storage 10% to 90% non-condensing
Altitude
Note: For operations above 2.4 km (8,000 ft), decrease the operating
temperature rating by 1.8°C for each 1,000 m (1°F for each 1,000 ft).
Operation 2.4 km (8,000 ft)
Storage 9.1 km (30,000 ft)
4-4
