SCS100/200/400 User Guide 5: Installation
5. Confirm the following:
a) The green Power LED lights up immediately.
b) After a few seconds, the green Link LED lights up.
c) After about 30 seconds, the green OK LED blinks green every two seconds.
d) If you installed a PC card, the PC card LED is solid green. If the LED is any other
color, see the LED section of the appropriate SCS chapter.
6. Continue with Assigning an IP Address.
Assigning an IP Address
You must assign an IP address to the SCS before you can perform any configurations.
We recommend you use the first method listed below, EZWebCon.
EZWebCon Method
We recommend using EZWebCon software for initially configuring the SCS. EZWebCon
is located on the distribution CD-ROM. The README file provides installation
instructions.
Use the following steps to assign an IP address using EZWebCon:
1. Start EZWebCon.
2. On the menu bar, click Action î Assign IP Address. The Assign IP address â
Select Device window displays.
Select the Device
3. Select the SCS that appears in the window and click Next. The Assign IP address -
Assignment Method Select window displays.
5-2
