The chapter describes the SCS400 connectors, LEDs, and specifications.
Connectors
Front Panel
The SCS400 front panel has four DB9 serial port connectors and an RJ45 Ethernet
connector.
SCS400 Front Panel
Side Panel
The SCS400 side panel has a reset button, two PC Card Slots, and two power
connectors.
SCS400 Side Panel
Reset Button
Screw
Terminal
Power
Connector
Power
Connector
PC Card Slots
