Lauda ECO GOLD - List of Alarm and Warning Codes

92 / 134 ECO Gold 09/2021
14 List of "Alarm and warning codes"
Alarms
Alarm code
Meaning
1
Low Level Pump
Pump runs too fast (low level)
2
Low Level Pump
Low level in the float
3
Overtemperature
Overtemperature (T > Tmax)
4
Pump blocked
Pump blocked (standstill)
5
Connection Command
Remote control unit command triggered in running operation
9
T ext Pt100
External Pt100 actual value is not present.
10
T ext analog
External analog actual value is not present.
11
T ext serial
External serial actual value is not present.
12
Input Analog 1
Analog module: Current interface 1, interruption.
13
Input Analog 2
Analog module: Current interface 2, interruption.
15
Digital Input
Error on digital input
Warnings
Code
0XX Control system
Meaning
Code
3XX SmartCool
Meaning
1
CAN receive overf
Overflow during CAN reception
1
CAN receive overf
Overflow during CAN reception
2
Watchdog Reset
Watchdog reset
2
Watchdog Reset
Watchdog reset
3
T_il limit active
til llmit active
3
adaption missing
No adaption run
4
T_ih limit active
tih llmit active
4
Pressure switch
activated
Pressure Switch in cooling circuit triggered
5
corrupt parameter
Inadmissible internal parameter
5
Clean condenser
Clean condenser
6
corrupt progr
Inadmissible programmer data
6
TO1 out of range
(Klixon)
Injection temperature outside value range
7
Invalid Parameter
Inadmissible parameter in memory
7
Invalid Parameter
Inadmissible parameter in memory
8
CAN system
Problem during internal data interchange
8
CAN system
Problem during internal data interchange
9
Unknown Modul
Unknown module connected
9
Unknown Modul
Unknown module connected
10
SW control too old
Software version of control panel too old
10
SW control too old
Software version of control panel too old
11
SW safety too old
Software version of protection too old
11
SW safety too old
Software version of protection too old
12
SW command too old
Software version of command remote
control unit too old
12
SW command too old
Software version of command remote
control unit too old
13
SW cool too old
Software version of cooling module too old
13
SW cool too old
Software version of cooling module too old
14
SW analog too old
Software version of analog too old
14
SW analog too old
Software version of analog too old
15
SW serial too old
Software version of serial too old
15
SW serial too old
Software version of RS 232 too old
16
SW contact old
Software version of contact module too old
16
SW contact old
Software version of contact module too old
17
SW Valve 0 old
Software version of solenoid valve too old
17
SW Valve 0 old
Software version of solenoid valve 0 too old
18
SW Valve 1 old
Software version of solenoid valve 1 too old
18
SW Valve 1 old
Software version of solenoid valve 1 too old
19
SW Valve 2 old
Software version of solenoid valve 2 too old
19
SW Valve 2 old
Software version of solenoid valve 2 too old
20
SW Valve 3 old
Software version of solenoid valve 3 too old
20
SW Valve 3 old
Software version of solenoid valve 3 too old
21
SW Valve 4 old
Software version of solenoid valve 4 too old
21
SW Valve 4 old
Software version of solenoid valve 4 too old
26
SW HTC old
Software version of high temperature cooler
too old
26
SW HTC old
Software version of high temperature cooler
too old
27
SW Ext Pt100 old
Software version of external Pt100 too old
27
SW Ext Pt100 old
Software version of external Pt100 too old
33
RTC wrong data
Internal clock defective
33
valve sm0 break
Cable of injection valve 0 defective
41
wrong net voltage
Incorrect mains voltage setting
34
valve sm1 break
Cable of injection valve 1 defective
42
no eco type
Device type not configured
35
valve sm2 break
Cable of injection valve 2 defective
43
no eco voltage
Mains voltage not configured
36
valve sm3 break
Cable of injection valve 3 defective
44
chiller missing
Chiller not running
37
output sm0
Triggering of injection valve 0 defective
45
Diff.voltages
Different mains voltage configured (head
and cooling underpart)
38
output sm1
Triggering of injection valve 1 defective
# of heaters
Setting the heater configuration
39
output sm2
Triggering of injection valve 2 defective
40
output sm3
Triggering of injection valve 3 defective
