94 / 134 ECO Gold 09/2021
Code
6XX Switch contacts
Meaning
Code
7, 8, 9, 10, 11,
16XX Solenoid valve
Meaning
1
CAN receive overf
Overflow during CAN reception
1
CAN receive overf
Overflow during CAN reception
2
Watchdog Reset
Watchdog reset
2
Watchdog Reset
Watchdog reset
9
Unknown Modul
Unknown module connected
3
No cooling liquid
No cooling liquid present (HTC)
10
SW Contr. too old
Software version of control panel too old
6
no unfill liquid too hot
No draining, because bath temperature is
too hot (HTC)
11
SW safety too old
Software version of protection too old
9
Unknown Modul
Unknown module connected
12
SW command too old
Software version of command remote
control unit too old
10
SW Contr. too old
Software version of control panel too old
13
SW cool too old
Software version of cooling module too old
11
SW safety too old
Software version of protection too old
14
SW analog too old
Software version of analog too old
12
SW command too old
Software version of command remote
control unit too old
15
SW serial too old
Software version of RS 232 too old
13
SW cool too old
Software version of cooling module too old
16
SW contact old
Software version of contact module too old
14
SW analog too old
Software version of analog too old
17
SW Valve 0 old
Software version of solenoid valve 0 too old
15
SW serial too old
Software version of RS 232 too old
18
SW Valve 1 old
Software version of solenoid valve 1 too old
16
SW contact old
Software version of contact module too old
19
SW Valve 2 old
Software version of solenoid valve 2 too old
17
SW Valve 0 old
Software version of solenoid valve 0 too old
20
SW Valve 3 old
Software version of solenoid valve 3 too old
18
SW Valve 1 old
Software version of solenoid valve 1 too old
21
SW Valve 4 old
Software version of solenoid valve 4 too old
19
SW Valve 2 old
Software version of solenoid valve 2 too old
26
SW HTC old
Software version of high temperature cooler
too old
20
SW Valve 3 old
Software version of solenoid valve 3 too old
27
SW Ext Pt100 old
Software version of external Pt100 too old
21
SW Valve 4 old
Software version of solenoid valve 4 too old
26
SW HTC old
Software version of high temperature cooler
too old
27
SW Ext Pt100 old
Software version of external Pt100 too old
Code
17XX Pt100/LiBus Module
Meaning
1
CAN receive overf
Overflow during CAN reception
2
Watchdog Reset
Watchdog reset
3
Ext_Pt_short
Line short on external t100
7
Invalid Parameter
Inadmissible parameter in memory
8
CAN system
Problem during internal data interchange
9
Unknown Modul
Unknown module connected
10
SW Contr. too old
Software version of control panel too old
11
SW safety too old
Software version of protection too old
12
SW command too old
Software version of command remote control unit too old
13
SW cool too old
Software version of cooling module too old
14
SW analog too old
Software version of analog too old
15
SW serial too old
Software version of RS 232 too old
16
SW contact old
Software version of contact module too old
17
SW Valve 0 old
Software version of solenoid valve 0 too old
18
SW Valve 1 old
Software version of solenoid valve 1 too old
19
SW Valve 2 old
Software version of solenoid valve 2 too old
20
SW Valve 3 old
Software version of solenoid valve 3 too old
21
SW Valve 4 old
Software version of solenoid valve 4 too old
26
SW HTC old
Software version of high temperature cooler too old
27
SW Ext Pt100 old
Software version of external Pt100 too old
