With Rec. Interval you define the time interval between recorded tem-
perature measurements (the values in brackets state the maximum
recording time).
The menu offers five options.
With Time axis you can define the temporal range over which the meas-
urements are to be displayed.
- automatic Program optimized display
- 9 min time axes set manually
- 45 min (depending on recording interval
- 2 h 15 min up to 144 h)
You can set the scaling to be used via the menu point
Time base.
- absolute Reference current time
- relative Start time "00:00:00"
With Temperature Scale you can define the scaling of the y axis (tem-
perature value).
- automatic Program optimized scaling
- manual Here you can define the limits
yourself.
Note: The temperature limits are entered via the menu point Temperature Limits.
This menu point only appears in the graphics menu when manual has been selected in the menu Temperature Scale.
