Pipe plan
50
230V; 50Hz ◆ 230V; 50/60Hz ◆ [230V; 60Hz] at Serialno.: A 20
RE 2xx
RE 004
F 4 Pressure switch CC80 24/18bar ES 045
M 2 Compressor GD 36 AC EMV 050
M 3 Fan 4715MS-10T-B50-B00 EML 052
J 1 Drier EO 003
J 2 Capillary HKA 114
J 3 Evaporator ----------
J 4 Bath ----------
RE 006
F 4 Pressure switch CC80 24/18bar ES 045
M 2+M 3+J 5 Cooling unit AZ 4419 Y/A EMK 186
J 1 Drier EO 003
J 2 Capillary HKA 114
J 3 Evaporator ----------
J 4 Bath ----------
RE 007
F 4 Pressure switch CC80 24/18bar ES 045
M 2 Compressor AZ 4419 Y-A EMV 011
M 3 Fan W2E 142-CC13-16 EML 042
J 1 Filter drier / receiver CNO 432 s EO 040
J 2 Injection valve TLK 0,3 R404A MOP 2,5 EVE 111
J 3 Evaporator ----------
J 4 Bath ----------
J 5 Condenser EOW 085
Y 1 Solenoid valve 2/2Wege 6mm Löt / Typ: 1028/2 EVM 077
[T 3 Trafo ESS 550VA Pr.208-230V;
sec.245V-50/60Hz BV:039-293
EIT 125
RE 010
F 4 Pressure switch CC25 28/18bar ES 048
M 2 Compressor NE2134GK Code: 952AG51B9AY EMV 056
M 3 Fan Typ:NET3T09PUN302/ 9W EML 057
J 1 Filter drier / receiver CNO732s EO 044
J 2 Injection valve TLEX-00216 EVE 128
J 3 Injection valve AEL 0,5 1-7bar; Typ: AEL 222200 EVE 135
J 4 Evaporator ----------
J 5 Bath ----------
J 6 Condenser D 38668 EOW 089
Y 1 Solenoid valve 2/2Wege 6mm Löt / Typ: 1028/2 EVM 077
RE 012
F 4 Pressure switch CC80 24/18bar ES 045
M 2 Compressor AZ 4419 Y-A EMV 011
M 3 Fan W2E 142-CC13-16 EML 042
J 1 Filter drier / receiver CNO 432 s EO 040
J 2 Injection valve TLK 0,3 R404A MOP 2,5 EVE 111
J 3 Evaporator ----------
J 4 Bath ----------
Y 1 Solenoid valve 2/2Wege 6mm Löt / Typ: 1028/2 EVM 077
[T 3 Trafo ESS 550VA Pr.208-230V;
sec.245V-50/60Hz BV:039-293
EIT 125
RE 020
F 4 Pressure switch CC80 24/18bar ES 045
M 2+M 3+J 5 Cooling unit UB 6144 Z/2 EMK 181
J 1 Drier DML 032 s EO 041
J 2 Injection valve TLK -0,5 R404A MOP 3,3 EVE 112
J 3 Evaporator ----------
J 4 Bath ----------
Y 1 Solenoid valve 2/2Wege 6mm Löt / Typ: 1028/2 EVM 077
[T 3 Trafo ESS 550VA Pr.208-230V;
sec.245V-50/60Hz BV:039-293
EIT 125
