Integral T process thermostats
1/21/2019/ YAWE 0026 Accessories 101
10 Accessories
4-way manifold for pump outflow and return; each connection
with separate shut-off.
for units with 3/4" pipe connections / 3/4" hose VT 2
for units with 3/4" pipe connections / 1/2" hose VT 3
for units with 1-1/4" pipe connections / 3/4" hose VT 4
Hose/ screw fitting: brass nozzle 1/2" / Nut 3/4" for all units with
3/4" pipe thread.
Metal hose insulated –60 – 200 °C
MTK 100 1 m long,
G ¾, DN 20, G ¾.
MTK 200 2 m long,
G ¾, DN 20, G ¾.
MTK 101 1 m long,
G 1¼*, DN 25, G 1.
MTK 201 2 m long,
G 1¼*, DN 25, G 1.
* for connection Integral
Platinum resistance thermometers to DIN EN 60751.
Temperature range –200 – 300 °C,
50 % response time 1 sec.,
4 mm dia. length 250 mm,
Accuracy Class A, Lemo plug.
Temperature range –100 – 200 °C,
4 mm dia., length 250 mm,
Accuracy class A, with attached Silicone cable
(2 m long) and 4-pin Lemo plug.
Clamping fitting 4 mm dia.,
suitable for Pt100-70 and Pt100-94.
Connecting cable, 2.5 m long,
Lemo plug suitable for Pt100-70
Cable length as specified
Remote control FBT,
1/3 19“; 4 elevation marks
Cable for Remote control FBT, length 5 m
Cable for Remote control FBT, length on demand max. 50 m
For further accessories please contact us ( 8.8).
