Integral T process thermostats
21/01/2019 / YAWE 0026 Starting up 79
7.7.3 Write commands (data commands to the thermostat)
Command
Explanation
OUT_SP_00_XXX.XX
Setpoint transfer with max. 3 digits before decimal point and max.
2 decimal digits behind.
OUT_SP_04_XXX.XX
TiH outflow temperature high limit.
OUT_SP_05_XXX.XX
TiL outflow temperature low limit.
OUT_PAR_00_XXX.XX
Setting of control parameter Xp for controller (0.1 – 10 °C).
OUT_PAR_01_XXX
Setting of the control parameter Tn (5 – 200 s).
OUT_PAR_04_XXX.XX
Setting of control parameter KPE (0.1 – 10.0).
OUT_PAR_05_XXX
Setting of control parameter TNE (5 – 200 s).
OUT_PAR_08_XXX.XX
Setting of the WIN value for tolerance range monitoring.
OUT_MODE_00_X
Keys: 0 = free / 1 = inhibited (corresponds to “KEY”).
OUT_MODE_01_X
Control: 0=internal / 1 = external.
START
To switch on the unit (standby modus or "Manual Start" ON if
mains are OFF).
When standby function is on auto (A) there is an error message
(ERR35).
STOP
Switches thermostat to standby (pump, heating, refrigeration unit
off). When standby function is on auto (A) there is an error
message (ERR35).
RMP_SELECT_X
Selection of the programme (1-5) to which the further instructions
apply. When the unit is switched on, programme 5 is selected
automatically.
RMP_START
Start the programmer.
RMP_PAUSE
Hold (pause) the programmer.
RMP_CONT
Restart the programmer after pause.
RMP_STOP
Terminate the programmer.
RMP_RESET
Delete the programmer.
RMP_OUT_00_XXX.XX_XXX
Set a programme segment (temperature and time). A segment is
added and appropriate values are applied to it.
RMP_OUT_02_XXX
Number of times the programme runs: 0 = unlimited / 1 – 250.
