Lauda Integral T 7000 W User Manual

Integral T process thermostats
14 Unpacking YAWE 0026 / 21/01/2019
3 Control and functional elements
1. Rating label
2. Bypass adjustment
3. Pump connections
4. Mains cable
5. Drain cock
6. Overflow
7. Exit and entrance cooling water connections R3/4”
(only water cooled devices W).
8. Level indication ( 6.2)
9. Filler opening for heat transfer liquid
10. Mains supply switch
11. Menu functions
12. Control unit tilted ( 4.7 and 4.8)
2
5
9
3
8
4
1
6
10
11
7
12

Lauda Integral T 7000 W Specifications

General

Brand	Lauda
Model	Integral T 7000 W
Category	Thermostat
Language	English
