Integral T process thermostats
80 Starting up YAWE 0026 / 21/01/2019
For ”_“ use also ” ” (blank character).
Response from thermostat “OK” or in case of error ”ERR_X“ (RS 485 interface e.g..
“A015_OK” or in case of error ”A015_ERR_X”.).
In different dates for one parameter (except for set point) are continuously transmitted
to the thermostat due to bugs, this can lead to the destruction of the storage location
in the thermostat. The storage locations can be overwritten up to 100.000 times.
Permitted data formats:
-XXX.XX
-XXX.X
-XXX.
-XXX
XXX.XX
XXX.X
XXX.
XXX
-XX.XX
-XX.X
-XX.
-XX
XX.XX
XX.X
XX.
XX
-X.XX
-X.X
-X.
-X
X.XX
X.X
X.
X
-.XX
-.X
.XX
.X
7.7.4 Read commands (data requested from the thermostat)
Command
Explanation
IN_PV_00
Read bath temperature (outflow temperature).
IN_PV_01
Read external temperature TE.
IN_PV_02
Read pump pressure in bar.
IN_SP_00
Read temperature setpoint.
IN_SP_03
Read current overtemperature switch-off point.
IN_SP_04
Read current outflow temperature limit TiH.
IN_SP_05
Read current outflow temperature limit TiL.
IN_PAR_00
Read current value of Xp.
IN_PAR_01
Read current value of Tn (201 = OFF).
IN_PAR_04
Read current value of KPE.
IN_PAR_05
Read current value of TNE (201 = OFF).
IN_PAR_08
Read current value of WIN for tolerance range monitoring.
IN_DO_01
State of the neutral contact:
0 = make-contact open/ 1 = make-contact closed.
IN_MODE_00
Keys: 0 = free / 1 = inhibited.
IN_MODE_01
Control: 0 = internal / 1 = external.
IN_MODE_02
Standby: 0 = Unit ON / 1 = Unit OFF; and in case of the activated function
"manual start" during the display "STArt/ 2 = auto.
TYPE
Read equipment type.
VERSION
Read software type.
STATUS
Read equipment status 0 = OK, -1 = error.
